Configuring a SIP Trunk Carrier in VICIdial: Registration, Account Entry and Inbound Routing

Adding a SIP trunk in VICIdial means filling in four fields correctly under Admin → Carriers → Add A New Carrier. This post walks through each one, covers both registration-based and IP-authenticated trunks, and finishes with inbound DID routing.

What Your Provider Needs to Give You

Before touching VICIdial, get these from the carrier:

• Authentication method — username/password registration, or IP whitelist
• SIP proxy hostname or IP, and port (usually 5060)
• Codecs permitted (ulaw, alaw, g729)
• DID numbers and the format they will be presented in (E.164 with +, national, or 10-digit)
• Whether they expect the DID in the SIP To: header or somewhere else

That last point causes more inbound failures than everything else combined. Ask explicitly.

The Four Carrier Fields

Registration String

Only used for credential-based trunks. Leave it empty for IP-authenticated ones.

register => username:password@sip.provider.com:5060/username

The trailing /username sets the extension your inbound calls will arrive on. Some providers want your DID there instead:

register => 15551234567:secretpass@sip.provider.com/15551234567

Account Entry

This is raw sip.conf content. VICIdial writes it into /etc/asterisk/sip-vicidial.conf.

Registration-based trunk:

[myprovider]
type=friend
username=15551234567
defaultuser=15551234567
secret=yourpassword
host=sip.provider.com
fromuser=15551234567
fromdomain=sip.provider.com
context=trunkinbound
insecure=port,invite
disallow=all
allow=ulaw
allow=alaw
dtmfmode=rfc2833
qualify=yes
nat=force_rport,comedia
canreinvite=no

IP-authenticated trunk — no secret, host is the carrier’s IP:

[myprovider]
type=friend
host=203.0.113.45
context=trunkinbound
insecure=port,invite
disallow=all
allow=ulaw
dtmfmode=rfc2833
qualify=yes
canreinvite=no

A few of these deserve explanation:

• context=trunkinbound — this is the VICIdial inbound context. If you set context=default, inbound calls will hit your outbound dialplan and fail in confusing ways.
• insecure=port,invite — tells Asterisk not to re-authenticate inbound INVITEs from a peer you already authenticate outbound. Required for most trunks.
• canreinvite=no — keeps media flowing through the server. You need this for call recording. If you set it to yes to save bandwidth, your recordings will be silent.
• nat=force_rport,comedia — correct when the server is behind NAT. On a server with a public IP and no NAT, nat=no is cleaner.

If your server is behind NAT, you also need this in Admin → Servers → Modify → External SIP settings, or directly in the globals of sip.conf:

externip=203.0.113.10
localnet=192.168.1.0/255.255.255.0

Globals String

Usually left blank. Use it if you want a variable available across the dialplan:

TRUNKNAME=myprovider

Then reference it as ${TRUNKNAME} in the Dialplan Entry. Handy when you are swapping carriers frequently in testing.

Dialplan Entry

exten => _91NXXNXXXXXX,1,AGI(agi://127.0.0.1:4577/call_log)
exten => _91NXXNXXXXXX,n,Dial(SIP/myprovider/${EXTEN:1},,tTo)
exten => _91NXXNXXXXXX,n,Hangup()

The peer name after SIP/ must match the bracketed name in your Account Entry exactly. Case matters.

Applying and Verifying

Carrier changes are written out by the keepalive script. To force it:

/usr/share/astguiclient/ADMIN_keepalive_ALL.pl
asterisk -rx "sip reload"

Check registration:

asterisk -rx "sip show registry"

You want Registered. Common states and what they mean:

• Request Sent — no response at all. Firewall blocking UDP 5060 outbound, or wrong hostname.
• Auth. Sent — credentials rejected. Check username, password, and whether the provider wants the DID as the username.
• Rejected — the provider actively refused. Usually an IP not yet whitelisted on their side.

Check peer state:

asterisk -rx "sip show peers"
asterisk -rx "sip show peer myprovider"

OK (23 ms) in the Status column means the qualify ping is working.

Firewall

Open the right ports before blaming the carrier:

# SIP signalling
firewall-cmd --permanent --add-port=5060/udp
# RTP media
firewall-cmd --permanent --add-port=10000-20000/udp
firewall-cmd --reload

Restrict these to the carrier’s IP ranges rather than leaving them open to the world. An open 5060 on a public IP will be scanned within hours.

Inbound DID Routing

Once calls arrive in trunkinbound, VICIdial routes them via its DID table. The default inbound context contains:

exten => _X.,1,AGI(agi-DID_route.agi)
exten => _X.,n,Hangup()

Then in Admin → Inbound → Show DIDs:

1. Add a DID whose DID Pattern matches exactly what the carrier sends. If they send +15551234567, the pattern must include the + or you must strip it in dialplan.
2. Set DID Route to IN_GROUP.
3. Select your in-group.

To strip a leading + before the AGI sees it:

[trunkinbound]
exten => _+X.,1,Goto(trunkinbound,${EXTEN:1},1)
exten => _X.,1,AGI(agi-DID_route.agi)
exten => _X.,n,Hangup()

Then on the agent side, in Admin → Users → Agent Interface Options, set Agent Choose Ingroups: 1, and in the campaign set Allow Inbound and Blended: Y with your in-group ticked under Allowed Inbound Groups.

Watching an Inbound Call

asterisk -rvvvvv

sip set debug peer myprovider

Place a test call to the DID and read the INVITE. The To: header tells you exactly what string your DID pattern must match. If the INVITE never appears, the call is not reaching your server and the problem is upstream — firewall, routing, or the provider has not pointed the DID at your IP yet.

Summary

Four fields, one context name, and one matching peer name. The parts that trip people up are context=trunkinbound for inbound, canreinvite=no if you want recordings, and matching your DID pattern to exactly what arrives in the To: header rather than what you assume the carrier sends.
